Felicity IVGM50KHP3G2

No.Felicity-18

High-Voltage Three-Phase Hybrid Inverter

Name: Felicity IVGM50KHP3G2
Brand: Hiwotech (Shanghai) Energy Technology Co. Ltd.
SKU: Felicity-18
Availability: InStock
Rating: 5 (1 reviews)

kW:

25kW

29.9kW

30kW

40kW

50kW

Felicitysolar T-REX Series High-Voltage Three-Phase Hybrid Inverter

Unleash industrial-grade energy flexibility with the T-REX Series high-voltage three-phase hybrid inverter—engineered by Felicitysolar to deliver powerful performance, intelligent control, and seamless scalability for commercial, industrial, and large-scale residential applications. Designed to make life full of hope, this inverter integrates cutting-edge technology to optimize energy use, ensure uninterrupted power, and maximize returns on your energy investment.

Core Features

Dual Monitoring Capabilities: Supports WiFi and Fsolar Smart Cloud Monitoring System for real-time data access, remote management, and performance tracking.

Flexible Three-Phase Operation: 100% unbalanced three-phase output allows versatile load connection without compromising performance.

Intuitive Touch Control: LCD touch screen enables easy parameter configuration (charging settings, work modes, voltage ranges) and status checks.

Outdoor-Ready Durability: IP65 protection rating ensures reliable operation in harsh environments, resistant to dust, rain, and extreme temperatures.

Uninterrupted Power Supply: EPS function and off-grid switching time <10ms prevent power loss for critical loads during grid outages.

Multi-Source Compatibility: Works seamlessly with generators, microgrids, smart loads, and microinverters (AC coupling supported).

Energy Optimization Modes: Time-of-Use, Sell-First, Zero Export To Grid Port, and Zero Export To CT options maximize energy savings and self-consumption.

High PV Harvest Efficiency: 8-channel PV input, 4-channel MPPT, and 1.3x overconfiguration capacity optimize solar energy capture.

Dual Battery Inputs: 2 independent battery ports (160V~800V range) reduce inter-cluster circulation, with 50A charge/discharge current per battery.

Scalable Parallel Connection: Supports up to 12 units in parallel to meet large-scale energy demands.

Auto-Restart Function: Automatically resumes operation when AC power recovers, ensuring hassle-free performance.

Technical Specifications

Parameter	T-REX-50KHP3G01	T-REX-40KHP3G01	T-REX-30KHP3G01	T-REX-29K9HP3G01	T-REX-25KHP3G01
Battery Input Data
Battery Type	LiFePO4 (LFP)	LiFePO4 (LFP)	LiFePO4 (LFP)	LiFePO4 (LFP)	LiFePO4 (LFP)
Battery Voltage Range	160~800Vdc	160~800Vdc	160~800Vdc	160~800Vdc	160~800Vdc
Max. Charging/Discharging Current	50A+50A	50A+50A	50A+50A	50A+50A	50A+50A
Number of Battery Inputs	2	2	2	2	2
PV String Input Data
Max. DC Input Power	65kW	52kW	39kW	38.87kW	32.5kW
Max. DC Input Voltage	1000Vdc	1000Vdc	1000Vdc	1000Vdc	1000Vdc
Min. DC Input Voltage	150Vdc	150Vdc	150Vdc	150Vdc	150Vdc
MPPT Voltage Range	200~850Vdc	200~850Vdc	200~850Vdc	200~850Vdc	200~850Vdc
No. of MPP Trackers	4	3	2	2	2
No. of Strings per MPP Tracker	2	2	2	2	2
AC Output Data
Rated AC Output Power	50kW	40kW	30kW	29.9kW	25kW
Max. AC Output Power	55kVA	44kVA	33kVA	32.9kVA	27.5kVA
Rated AC Voltage	220/380Vac, 230/400Vac (-20%~+15%)	220/380Vac, 230/400Vac (-20%~+15%)	220/380Vac, 230/400Vac (-20%~+15%)	220/380Vac, 230/400Vac (-20%~+15%)	220/380Vac, 230/400Vac (-20%~+15%)
Rated AC Frequency	50/60Hz (45~55Hz/55~65Hz)	50/60Hz (45~55Hz/55~65Hz)	50/60Hz (45~55Hz/55~65Hz)	50/60Hz (45~55Hz/55~65Hz)	50/60Hz (45~55Hz/55~65Hz)
AC Wiring Mode	3L+N+PE	3L+N+PE	3L+N+PE	3L+N+PE	3L+N+PE
Power Factor	0.8 (leading) ~ 0.8 (lagging)	0.8 (leading) ~ 0.8 (lagging)	0.8 (leading) ~ 0.8 (lagging)	0.8 (leading) ~ 0.8 (lagging)	0.8 (leading) ~ 0.8 (lagging)
Max. Efficiency	97.6%	97.6%	97.6%	97.6%	97.6%
General Specifications
Protection Degree	IP65	IP65	IP65	IP65	IP65
Operating Temperature Range	-25°C~60°C (>50°C derating)	-25°C~60°C (>50°C derating)	-25°C~60°C (>50°C derating)	-25°C~60°C (>50°C derating)	-25°C~60°C (>50°C derating)
Humidity	0~95% (non-condensing)	0~95% (non-condensing)	0~95% (non-condensing)	0~95% (non-condensing)	0~95% (non-condensing)
Net Weight	85.6KG	85.6KG	85.6KG	85.6KG	85.6KG
Gross Weight	102.3KG	102.3KG	102.3KG	102.3KG	102.3KG
Product Dimension	940×582×340MM	940×582×340MM	940×582×340MM	940×582×340MM	940×582×340MM
Package Dimension	1114×774×469MM	1114×774×469MM	1114×774×469MM	1114×774×469MM	1114×774×469MM
Communication	RS485, CAN, WiFi/GPRS	RS485, CAN, WiFi/GPRS	RS485, CAN, WiFi/GPRS	RS485, CAN, WiFi/GPRS	RS485, CAN, WiFi/GPRS
Warranty	10 Years	10 Years	10 Years	10 Years	10 Years
Certifications	NRS 097-2-1, VDE4105, EN50549-1, AS 4777.2, IEC/EN 62109-1/2	NRS 097-2-1, VDE4105, EN50549-1, AS 4777.2, IEC/EN 62109-1/2	NRS 097-2-1, VDE4105, EN50549-1, AS 4777.2, IEC/EN 62109-1/2	NRS 097-2-1, VDE4105, EN50549-1, AS 4777.2, IEC/EN 62109-1/2	NRS 097-2-1, VDE4105, EN50549-1, AS 4777.2, IEC/EN 62109-1/2

Notes

Product specifications may vary during continuous improvements. Please contact us for the latest details.

*Refer to Felicitysolar's Warranty Policy for applicable conditions.

Parallel operation requires one master inverter and up to 11 slave inverters, with unique CAN IDs for each unit.

Product Highlights

Industrial-Grade Performance: High voltage input (up to 800Vdc) and large power output make it ideal for commercial/industrial projects and large residential setups.

Comprehensive Protection: Integrated safeguards include overvoltage/overcurrent protection, anti-islanding, insulation resistor detection, and residual current monitoring.

Flexible Work Modes: Supports On-Grid, Off-Grid, UPS, and peak-shaving modes to adapt to diverse energy needs.

Easy Installation & Maintenance: Wall-mounted design, clear port labeling, and easy-to-replace components simplify setup and upkeep.

Global Grid Compatibility: Complies with major grid regulations (VDE4105, AS 4777.2, G99, etc.) for worldwide deployment.
