Felicity FLA48300

No.Felicity-11

FLA Series 51.2V LiFePO4 Battery Pack

15kWh
Nominal Energy
  • Felicity FLA48300
  • Felicity FLA48300
  • Felicity FLA48300
  • Felicity FLA48300
  • Felicity FLA48300
  • Felicity FLA48300

Description

Felicitysolar FLA Series 51.2V LiFePO4 Battery Pack (FLA48300)

Experience top-tier energy storage with the FLA48300 from Felicitysolar—an advanced 51.2V LiFePO4 battery pack that blends safety, scalability, and reliability to power your life with hope.

Core Features

  • Premium LiFePO4 Chemistry: Delivers higher safety performance and an extended cycle life for long-term use.
  • Comprehensive Protection: Built-in smart BMS, circuit breaker, and fuse shield against potential risks.
  • Dual Installation Options: Supports both wall-mounted and floor-mounted setups to fit diverse spaces.
  • Wide Inverter Compatibility: Seamlessly integrates with leading inverter brands on the market.
  • Scalable Expansion: Parallel connection for up to 15 units, unlocking a maximum capacity of 225kWh.
  • Remote Monitoring: Built-in WiFi enables real-time tracking of battery data anytime, anywhere.
  • Enhanced Safety: Equipped with an aerosol fire extinguishing system for added peace of mind.
  • Easy Fuse Replacement: Conveniently replace the battery fuse when needed, minimizing downtime.

Technical Specifications

Parameter Details
Model FLA48300
Battery Type LiFePO4
Nominal Energy 15kWh
Nominal Capacity 300Ah
Nominal Voltage 51.2V
Operating Voltage 44.8-57.6V
Recommend Charge/Discharge Current 120A
Max. Continuous Charge/Discharge Current[1] 150A
Peak Charge/Discharge Current(15s) 200A
Scalability Max. 15 pcs in Parallel (225kWh)
Depth of Discharge (DOD) ≥95%
Display Type LCD
Protection Degree IP21
Working Temperature Range Charge: 0°C ~ 55°C; Discharge: -20°C ~ 55°C
Storage Temperature Range 0°C ~ +35°C
Humidity 5% - 95%
Altitude ≤2000m
Communication RS485/CAN
Cycle Life ≥6000 Cycles (25°C±2°C, 0.5C/0.5C, 90% DOD, 70% EOL)
Installation Wall-Mounted / Floor-Mounted
Protection Built-in Smart BMS, Breaker, Fuse
Warranty Period 7 Years
Certification UN38.3, CE-EMC, IEC 62619
Product Weight 135KG
Package Weight 160KG
Product Dimension 480X1100X300MM
Package Dimension 1150X635X498MM

Notes

[1] Max. Continuous Charge/Discharge Current is affected by temperature and SOC.
Product specifications may vary during continuous improvements. Please contact us for the latest details.
*Refer to Felicitysolar's Warranty Policy for applicable conditions.

Product Highlights

  • Real-Time Status Tracking: LCD display offers clear visibility of battery performance and operating status.
  • Dual Connectivity: Built-in WiFi and Bluetooth enable convenient remote monitoring and operation.
  • Robust Safety Design: Aerosol fire extinguishing system and multi-layer protection ensure all-round safety.
  • High Scalability: Parallel connection support meets growing energy demands for homes or commercial spaces.
  • Low Maintenance: Easy fuse replacement design reduces hassle and keeps the system running smoothly.
