Elevate your energy storage experience with Felicity Solar’s 25.6V LiFePO4 Battery Pack—designed to make life full of hope through reliable, efficient, and safe power solutions. Available in two models (FLA24100: 2.56kWh, FLA24200: 5kWh), this low-voltage battery pack combines cutting-edge technology with user-centric design, perfect for residential and small commercial solar energy systems.
Core Features
Scalable Expansion: Parallel connection support for up to 15 units, delivering a maximum capacity of 38.4kWh (FLA24100) or 75kWh (FLA24200) to meet growing energy needs.
Remote Monitoring: Built-in WiFi and Bluetooth enable real-time tracking of battery data via mobile devices, keeping you informed of status anytime, anywhere.
Flexible Installation: Choose between wall-mounted or floor-mounted setup to fit limited spaces and diverse installation scenarios.
Superior Safety & Longevity: LiFePO4 chemistry ensures higher safety (thermal stability, no thermal runaway risk) and a long cycle life of over 6,000 cycles at 0.2C/25°C (80% DOD).
Comprehensive Protection: Equipped with smart BMS (Battery Management System), breaker, and fuse to safeguard against overcharge, over-discharge, short circuit, and over-temperature.
Wide Compatibility: Seamlessly works with leading inverter brands, ensuring hassle-free integration into existing or new solar systems.
Reliable Warranty: Backed by a 7-year warranty, reflecting our confidence in product quality and performance.
Technical Specifications
Model
FLA24250
Battery Type
LiFePO4
Nominal Energy
6.4kWh
Nominal Voltage
25.6V
Operating Voltage
22.4-28.8V
Recommend Charge/Discharge Current[1]
≤150A
Recommend Charge/Discharge Power[1]
≤3,750W
Maximum Charge/Discharge Current(15s)
200A
Maximum Charge/Discharge Power(15s)
5,000W
Scalability
Max. 15 pcs in Parallel (96kWh)
Depth of Discharge (DOD)
≥95%
Communication
RS485/CAN
Protection Degree
IP21
Cycle Life[2]
≥6,000 Cycles
Charging Temperature Range
0°C~+55°C
Discharging Temperature Range
-20°C~+55°C
Display Type
LCD+LED
Installation
Wall-Mounted / Floor-Mounted
Protection
Built-in Smart BMS, Breaker, Fuse
Warranty Period
7 Years
Certification
UN38.3
Product Weight
52.5KG
Package Weight
57KG
Product Dimension
527X400X280MM
Package Dimension
Notes: 1. Maximum continuous charge/discharge current varies by temperature and SOC. 2. Cycle life test conditions: 0.2C charging/discharging @25°C, 80% DOD. Product specifications are subject to change due to continuous improvement. Please contact us for the latest details. Warranty terms apply per Felicity Solar’s official Warranty Policy.
