| Parameter | FLA24100 |
|---|---|
| Battery Type | LiFePO4 |
| Nominal Energy | 2.56kWh |
| Nominal Voltage | 25.6V |
| Operating Voltage Range | 22.4-28.8V |
| Recommended Continuous Charge/Discharge Current | ≤100A |
| Recommended Continuous Charge/Discharge Power | ≤2,500W |
| Maximum Charge/Discharge Current (15s) | 150A |
| Maximum Charge/Discharge Power (15s) | 3,750W |
| Maximum Parallel Units | 15 (38.4kWh total) |
| Depth of Discharge (DOD) | ≥95% |
| Communication Interface | RS485/CAN |
| Protection Degree | IP21 |
| Charging Temperature Range | 0°C to +55°C |
| Discharging Temperature Range | -20°C to +55°C |
| Display Type | LCD + LED |
| Installation Type | Wall-Mounted / Floor-Mounted |
| Certifications | UN38.3 |
| Product Weight | 27KG |
| Package Weight | 30KG |
| Product Dimension (L×W×H) | 454×380×154MM |
| Package Dimension (L×W×H) | 543×472×232MM |
